Engineering Graphics Principles with Geometric Dimensioning and Tolerancing, 2nd Edition eBook

Delivery: Can be download immediately after purchasing. For new customer, we need process for verification from 30 mins to 12 hours.
Version: PDF/EPUB. If you need EPUB and MOBI Version, please contact us.
Compatible Devices: Can be read on any devices.

Engineering Graphics Principles with Geometric Dimensioning and Tolerancing embodies a practical experience, and introduces a new approach for learning the basic concepts and applications of engineering graphics, and geometric dimensioning and tolerancing. The materials in the book and the accompanying digital download comply with the ASME Y14.5M-1994 standard, and use various instructional methods to heighten their effectiveness as a teaching and training tool.

There are no prerequisites for using these materials. If you have had manual or CAD graphics, or machine shop background in high school, college, or in an industrial application, you may find some of the introductory materials repetitive and less challenging. However, because all of the materials parallel the ASME Y14.5M – 1994 standard, there is a strong possibility that some portion of the information will be new and challenging to you.

Engineering Graphics Principles with Geometric Dimensioning and Tolerancing is comprised of both a print book and digital content. A major portion of the instructional material is included on the digital download. The digital materials include exercises and self-evaluation materials.

More than anything else, these materials deal with modeling and defining part geometry on mechanical components and assemblies. Everything in the materials point to the importance of appropriate specification and control of part geometry, including dimensioning, tolerancing, and verification of geometric characteristics and relationships.

The book begins with an abbreviated overview of the historical significance of graphics as a means of conveying and documenting design iterations and modeled configurations. However, it stops short of philosophizing on the design process and cycles of design.

Four specific modules have been designed to assist you in the introduction and/or review of basic concepts related to elements of view selection, orientation, projection, and standards for defining geometry. These units focus on orthographic projection, auxiliary views, sectioning, and coordinate dimensioning and tolerancing.

This is a digital product.

Engineering Graphics Principles with Geometric Dimensioning and Tolerancing 2nd Edition is written by E. Max Raisor and published by SDC Publications, Inc.. The Digital and eTextbook ISBNs for Engineering Graphics Principles with Geometric Dimensioning and Tolerancing are 9781630569310, 1630569313 and the print ISBNs are 9781630571214, 1630571210.
