Defects in HIgh-k Gate Dielectric Stacks: Nano-Electronic Semiconductor Devices, 1st Edition eBook

Delivery: Can be download immediately after purchasing. For new customer, we need process for verification from 30 mins to 12 hours.
Version: PDF/EPUB. If you need EPUB and MOBI Version, please contact us.
Compatible Devices: Can be read on any devices.

The goal of this NATO Advanced Research Workshop (ARW) entitled “Defects in Advanced High-k Dielectric Nano-electronic Semiconductor Devices”, which was held in St. Petersburg, Russia, from July 11 to 14, 2005, was to examine the very complex scientific issues that pertain to the use of advanced high dielectric constant (high-k) materials in next generation semiconductor devices. The special feature of this workshop was focus on an important issue of defects in this novel class of materials. One of the key obstacles to high-k integration into Si nano-technology are the electronic defects in high-k materials. It has been established that defects do exist in high-k dielectrics and they play an important role in device operation. However, very little is known about the nature of the defects or about possible techniques to eliminate, or at least minimize them. Given the absence of a feasible alternative in the near future, well-focused scientific research and aggressive development programs on high-k gate dielectrics and related devices must continue for semiconductor electronics to remain a competitive income producing force in the global market.

This is a digital product.

Defects in HIgh-k Gate Dielectric Stacks: Nano-Electronic Semiconductor Devices 1st Edition is written by Evgeni Gusev and published by Springer. The Digital and eTextbook ISBNs for Defects in HIgh-k Gate Dielectric Stacks are 9781402043673, 1402043678 and the print ISBNs are 9781402043659, 1402043651.
